ProRF is an elegantly designed RFID access control terminal. Its IP67 waterproof & dustproof level enables direct outdoor installation, and is even able to normally operate under extreme weather conditions in a temperature range of -20°C~65°C. As an advanced terminal, ProRF is equipped with 2 relays of lock, alarm control, SRB for enhanced security, and auxiliary smoke detection input for fire security linkage. Its large storage capacity of up to 100,000 users/cards and 600,000 transactions is perfectly applicable to mega-size enterprise.
Comprehensive and stable software
Comprehensive and stable software
Comprehensive after-sales service coverage
| Users / Card Capacity | 60,000 (Standard), 100,000 (Optional) |
| Transaction Capacity | 600,000 |
| Communication | TCP / IP / RS232 / RS485* / Wiegand Input / Output / Security Relay Box |
| Access Control Interface | Lock Relay Output / Alarm Output / Auxiliary Input / Exit Button / Door Sensor / Doorbell Output |
| Hardware | 1.0GHz High Speed CPU / Memory 64MB RAM / 128MB Flash / 125KHz EM Reader /13.56 MHz MF (Optional) / Beep & LED Indicator |
| Standard Function | Access Levels / Groups / Holidays / DST / Bell Schedule |
| Compatibility | Wiegand Slave Reader / ZKBioSecurity |
| Special Function | IP67 |
| Operating Temperature | -20 °C ~ 65 °C (-4 °F ~ 149 °F) |
| Dimension | 131* 80 * 20.6 mm |
| Operating Voltage | 12V DC |
| Current Draw | < 500 mA |
