mTS1000 Series is mainly made of SUS304 stainless steel which boosts up durability. Its compact design provides a space-saving and cost-efficient solution in multiple scenarios, such as corporate offices and theme parks. The built-in LED pictogram provides user a clear directional guidance. In case of emergency, the bi-directional tripod turnstile supports wireless remote control to execute the drop arm function efficiently for free passage.
Comprehensive and stable software
Comprehensive and stable software
Comprehensive after-sales service coverage
| Power Requirements | AC110V/220V, 50/60Hz |
| Power Consumption | Running: 40W / Standby: 10W |
| Operating Temperature | -28°C to 60°C |
| Operating Humidity | 5%RH to 80%RH |
| Operating Environment | Indoor/Outdoor (if sheltered) |
| Speed of Throughput | RFID: Maximum 25/minute / Fingerprint: Maximum 20/minute |
| Lane Width | 478(mm) |
| Footprint | 250 × 138(mm) |
| Arm Length | 478(mm) |
| Dimension (L×W×H) | 798 × 750 × 950(mm) |
| Package Dimension (L×W×H) | 380 × 450 × 1150(mm) |
| Net Weight | 35kg |
| Gross Weight with Package | 40kg |
| LED Pictogram Indication | Yes |
| Control System | Input controlled by dry contact |
| Cabinet Material | SUS304 (optional SUS316) |
| Lid Material | Acrylic |
| Barrier Material | SUS304 |
| Barrier Movement | Rotated |
| Emergency Mode | Support (power off drop arm) |
| Security Level | Medium |
| MCBF | 2 million |
| Options/Accessories | Cardbox, Remote control, QR reader |
| Certification(s) | CE and FCC |
Features
• SUS304 stainless steel housing
• Bi-directional tripod turnstile with arm drop function
• LED pictograms for intuitive use and high throughput in both directions
• High quality at a cost effective price
• Low power consumption
• Wide range of accessories
• Easy and simple installation process
